Explosion Proof Vertical Condenser Rotary Evaporator Rotavap vacuum Concentrator

Product Description

The rotary evaporator is made according to the principle of constant temperature heating and film evaporation under vacuum and negative pressure. The rotary evaporator uses stepless speed regulation to make the glass rotating bottle rotate at a constant speed, and the materials form a large area uniform film on the bottle wall.
Then, the rotating bottle is evenly heated by the intelligent constant temperature water bath, evaporated at a high speed under vacuum, and the solvent vapor is cooled by the high-efficiency glass condenser and recycled in the collection bottle.

Features:

1. Big LCD screen with menu interface displaying several data; rotary switch easy to operate.
2. Heating bath with T ef lo n coating, which is easy to clean, anti-corrosive, and high temperature resistant as well.
3. Temperature of R series can reach up to 99ºC. Heater stops heating in over-temperature conditions.
4. Special design of bottle pulling switch, which is easy to disassemble the evaporation flask.
5. Sealing made up of imported PTFE with a unique technique.
6. Both screen touch control and button press automatic lifting are available, easy, and safe to use.
7. DC rotating motor of 70w power starts steadily.
8. Vertical condenser with drip point design prevents backflow.
9. Intermittent positive and negative rotating function with timer function for drying process, maximum rotating speed up to 310rmp/min.
10. Vacuum degree can be controlled with the vacuum gauge and vacuum valve, which can prevent pump oil from backflow and improves the success rate of experiment.
11. Heating bath with safe handle, which is heat insulated and prevents scald. The medium sized heating bath helps heat fast.
12. Equipped with a protection cap, which is heat preserved, energy saving and anti-spill and anti-boiling.

Application:
Mainly used for concentration, crystallization, drying, separation and solvent recovery in pharmaceutical, chemical and biopharmaceutical industries.
