XI'AN BIOLAND INSTRUMENT CO.,LTD experimental multifunctional plant extraction equipment ,extraction, concentration and recovery unit is a new product developed by our company on the basis of learning from similar products at home and abroad. It is suitable for the extraction and concentration of Chinese herbal and natural products (water and organic solvents) and volatile aromas. The recovery of oil, the concentration specific gravity is 1.1-1.3. Equipment composition: extraction tank, reflux condenser, oil-water separator, vacuum pump, recovery tank, concentration tank, temperature controller, stainless steel frame and connecting pipe valves, instruments, etc.

plant extraction equipment On-line ultrasonic extraction function is optional: using energy-concentrated ultrasonic generator, due to the unique physical effect and cavitation effect of ultrasonic, it can promote the breakage or deformation of plant cell tissue, vibration, acceleration impact, and sound pressure between solute particles The shear equivalent stress is strengthened, and the extreme high temperature and high pressure at the local point of the material makes the large-volume materials fully contact the ultrasonic probe, accelerates the uniform precipitation of the active ingredients in the raw material, and the extraction rate is significantly higher than that of the traditional process. Ultrasonic extraction is extraction at room temperature, which effectively reduces the loss of heat-sensitive components. Optional frequency range: 15KHz, 20KHz, 28 KHz, 30 KHz, 35 KHz, 40 KHz, 50 KHz, 60KHZ.

100L 200L Ultrasonic-assisted herbal plant Extraction and Concentration machine
