A.The water extraction machine of extraction tank is a conical-type structure, atmospheric pressure vessel, four-ear brackets; extraction tank slag door diameter, 3 air cylinders (material: carbon steel) pneumatic control push-pull self-locking quick-opening revolving door (material: carbon steel).

B. water extraction machine of The barrel is designed to be jacketed for heating, and the heating is even and fast; the bottom is with hard tube liquid outlet device which can pass through the steam to backlash.

C.water extraction machine of Condenser:Shell material 304 material /3mm, tube sheet and heat exchange tube is 304/φ25×1.5mm; cooling water inlet and outlet Ø 32.

D water extraction machine of Cooler

E.water extraction machine of Separator:Structural: vertical; upper and lower flange plates, bolts fasten, sight glass.Design pressure: normal pressure.

F. water extraction machine of Dual filter: with three-way ball valve, vent valve and internal connection pipes
