50L Laboratory Glass Nutsche Filter
Laboratory Glass Nutsche Filter,Nutsche Filter Reactor
Laboratory Glass Nutsche Filter, Glass Nutsche Filter ,vacuum jacketed reactor
Product Detail
Product Specifications of Laboratory Glass Nutsche Filter
Solid phase reactor/Laboratory Glass Nutsche Filter
Reactor capacity 10l~150L
Can be used for solid phase synthesis, cyclization, cracking and other processes.
Material: High borosilicon glass or stainless steel
Pressure: -0.098Mpa~0Pa
Operating Temperature: -90°C~250°C
Various specifications of filter base plate, filter mesh optional, filter aperture 0.1~200μm
Mechanical lifting nozzle cover and filter bottom plate for easy material discharge, nozzle body cleaning and filter replacement
Solid phase reactor/Laboratory Glass Nutsche Filter
Reactor capacity 10l~150L
Can be used for solid phase synthesis, cyclization, cracking and other processes.
Material: High borosilicon glass or stainless steel
Pressure: -0.098Mpa~0Pa
Operating Temperature: -90°C~250°C
Various specifications of filter base plate, filter mesh optional, filter aperture 0.1~200μm
Mechanical lifting nozzle cover and filter bottom plate for easy material discharge, nozzle body cleaning and filter replacement
Stainless Steel Frame
Laboratory Glass Nutsche Filter adopts vacuum negative pressure for filtration, high borosilicon glass reactor body, has excellent physical and chemical properties, transparent bottle body, can conveniently observe the experimental process, can be used in biopharmaceutical, precious metal purification, material crystallization, petrochemical and other fields
Production of Laboratory Glass Nutsche Filter characteristics:
1. The filter device is made of tetrafluoro material, with a liquid guide groove inside. The screen plate (tetrafluoro, stainless steel, titanium, various specifications of filter cloth filter film is optional) is pressed into the tetrafluoro filter device, the silk ring screw is fixed, easy to remove and replace
2. Can work under constant pressure and vacuum conditions, vacuum under stationary state can reach -0.095MPa below
3. Digital display stirring speed, variable frequency, constant speed stirring system, smooth operation
Single or double layer PTFE stirring paddle (stirring blade), corrosion resistant
4. Non-dead cavity design anti-corrosion discharge valve
5. Cooling or heating solution of the intermediate layer after the reaction is complete, can exclude clean, no accumulation of liquid
6. The overall structure is novel, practical and beautiful
Application of Laboratory Glass Nutsche Filter:
Using GG17 high borosilicon double layer glass boiler body, configured with PTFE filter base plate, suitable for mixing stirring reaction of materials under negative pressure conditions, solid phase synthesis and cracking, material crystallization, filtration filtration and other experimental operation
